Analog Input/Output Modules
Versatile, robust and highly compact
With their metal housing, the analog input and output modules of the M100 series are highly compact, extremely robust and packed with functions. The M100 hardware design minimizes failures caused by operating conditions and guarantees high-efficiency operational performance over the long run.
The cost and performance optimized design of complex automation solutions involves a large number of different sensor and actuator types. The standard 10 V and 4 mA to 20 mA interfaces are often not sufficient to achieve demanding objectives. With the universal talent UIO106, a single module type covers all common analog and digital signals for inputs and outputs that can be configured individually for each channel. The extensive versatility of the module is rounded off by a wide range of additional functions such as counters, encoders or pulse width modulation.
Temperature measurements represent the largest group of analog interfaces in industrial automation. All the more reason why technical perfection and cost-effectiveness are important requirements here. Both requirements are perfectly covered by the AIO112 modules. Up to 12 Pt100/Pt1000 sensors can be cost-effectively connected to a single module using a 2 wire connection technology. If not all channels are required for temperature measurement, up to 6 channels can be used as current outputs.
The range of the AIO104/I module type extends from current loops, high-impedance voltage measuring ranges, temperature measurement via Pt100/Pt1000 sensor in 2-, 3- and 4-wire technology, as well as thermo-couples and free configurable resistance measurement. The module offers the advantages of an extremely versatile multi-signal type analog input/output module combined with channel-wise galvanic isolation. The integrated measuring range and measured value monitoring enable both sensor circuit faults as well as process alarms to be implemented easily.
The AIM112 module type is particularly useful when a large number of different interfaces requires a correspondingly large variety of types of acquisition modules. Up to 12 analog inputs can be individually configured to the desired signal type. Alternatively, channel types for all industrially relevant thermocouples including integrated characteristic linearization are available for measuring very wide temperature ranges.
Analog Input and Output Modules
Product overview
Module | Type | Channels |
UIO106 | Universal Input/Output Module | 6 analog and digital inputs and outputs Up to 6 additional channels depending on the required signal type |
UIO108 | Universal Input/Output Module | 8 analog and digital inputs and outputs Up to 8 additional channels depending on the required signal type |
AIO104/I | Analog Input/Output Module | 4 analog inputs and outputs isolated Up to 4 additional channels depending on the required signal type |
AIO112 | Analog Input/Output Module | 12 analog inputs and outputs RTD/AOI |
AIO116 | Analog Input/Output Module | 16 analog inputs and outputs RTD/AOI |
AIM112 | Analog Input Module (Multi) | 12 analog inputs |
