Digital Input/Output Modules
Efficiency for all channel types
The range of digital input/output modules for Bachmann automation systems offers the perfect solution for every requirement concerning channel types. A selection from the standard 6-channel variant up to the ultra-compact 80-channel module guarantees the right module for every purpose.
Combined I/O modules permit the operating mode (DI/DO) of each individual channel to be configured by the user. In addition to the globally standardized 24 V DC input signal, 48 V DC modules are also available for the power station sector.
M200 I/O modules from Bachmann electronic facilitate not only the typical PLC process image access, but also permit individual addressing at any time during the program sequence (direct access). In order to execute programmes in an event-driven manner, it is possible to configure individual digital inputs and their state transitions as interrupt sources. All modules support transmission via FASTBUS (fiber optic cable), CAN or PROFINET and offer a high degree of flexibility in the design of sophisticated automation solutions.
Digital Input/Output Modules
Product overview
Module | Type | Inputs | Outputs |
DI216 | Digital Input Module | 16 | 0 |
DI232/x | Digital Input Module | 32 | 0 |
DO216 | Digital Output Module | 0 | 16 |
DO232 | Digital Output Module | 0 | 32 |
DIO216/x | Digital Input/Output Module | 0 to 16 | 0 to 16 |
DIO232 | Digital Input/Output Module | 16 to 32 | 0 to 16 |
DIO248 | Digital Input/Output Module | 16 to32 | 16 to 32 |
DIO264 | Digital Input/Output Module | 24 to 40 | 24 to 40 |
DIO280 | Digital Input/Output Module | 32 to 48 | 32 to 48 |
DOR206/230 | Digital Relay Output Module | 0 | 6 relays |
