The backplane combines the node adapter and the I/O modules into a mechanically robust EMC compliant unit. Completely assembled I/O stations can thus be pretested and subsequently transferred to the application without further modification. Backplanes allow for real-time communication between modules as well as with the node adapter and provide the power supply to the logic side of the modules.

Thanks to M100’s IP40-compliant design and mounting concept, stations can be mounted directly on or in a machine, either on a DIN rail or with screw fixings. Individual modules are securely attached with screws, remaining stable even under considerable vibration or impact loads.

Empty slots on backplanes are useful for optional retrofits, machine variants or for keeping reserve space in plant construction. The BPC101 backplane slot cover protects each slot from mechanical influences, electrostatic discharge and contamination.

AdobeStock_66310780_lichtpunkt_bearb

System Modules

Product overview

ModuleType
BPR100Backplanes
BPS100Backplanes
BPC101Backplanes
