As the leading provider in the field of soft motion control, Bachmann electronic offers a flexible line of modules for directly wired motion control.

Bachmann modules cover all types of data acquisition, from fast pulse and incremental encoder cards with bandwidths up to 8 MHz to SSI (Serial Synchronous Interface). The possibility of controlling the drives with analog signals (voltage), step motor outputs or PWM output channels allows flexible configuration.

All Bachmann encoder interface modules offer precise synchronizability as well as comprehensive functional support for the programmer.


Function Modules

Product overview

CNT204/xCounter Modules
ISI222/xEncoder Interface Modules
PWM202Pulse Width Modulation Module
ACR222/2 Axis Controller Module
PVA204, PVA208 Proportional Valve Amplifiers

System overview
